Page #219 background image
Configuring the Cisco SPA500S Attendant Console
Setting Up the Cisco SPA500S Attendant Console
Cisco Small Business SPA300 Series, SPA500 Series, and WIP310 IP Phone Administration Guide 217
9
Configuring BroadSoft Busy Lamp Field Auto-Configuration
Rather than configuring each BLF key individually, you can enter a single
SUBSCRIBE URI and automatically generate configuration scripts for BLF keys for
all users on the monitored list.
To configure BLF auto-configuration:
STEP 1 Log in to the configuration utility.
STEP 2 Click Admin Login.
STEP 3 Click advanced.
STEP 4 Click the Att Console tab.
STEP 5 In the BLF List URI field, enter the URI to generate BLF keys:
listname@domain.com;vid=2
Where:
listname: Name of the list.
domain.com: Name of the domain.
vid: Assigns keys to the extension. By default, the SUBSCRIBE is sent when
“Ext 1” is registered. You must set the “vid=” to a different value to change
this behavior.
For example:
mylist@broadsoft.com;vid=2
STEP 6 Click Submit All Changes.
Attendant Console Parameters
Parameters in the Attendant Console web page are described in the following
table. For information about Unit/Key syntax, see the previous sections.
