Cisco SPA303 Administration Guide

Configuring Lines and Extensions
Configuring Lines
Cisco Small Business SPA300 Series, SPA500 Series, and WIP310 IP Phone Administration Guide 41
2
- mp3: pressing the line button starts the mp3 player.
- weather: pressing the line button accesses weather information.
- news: pressing the line button accesses news.
For example, to configure line 4 for the mp3 player:
fnc=mp3
STEP 6 Click Submit All Changes. After the phone reboots, configured lines glow orange
and display the following icons next to the extension label:
• xml: XML icon
• mp3: mp3 player icon (Cisco SPA525G/525G2)
• news: RSS icon
• weather: thermometer icon
Configuring Line Key LED Patterns on the Cisco SPA300
Series or Cisco SPA500 Series IP Phone
You can customize the LED patterns for the line keys on the phone by entering
letters for the color or pattern in the LED pattern fields.
To configure Line Key LED patterns:
STEP 1 Log in to the configuration utility.
STEP 2 Click Admin Login and advanced.
STEP 3 Click the Phone tab.
STEP 4 Under Line Key LED Pattern, use the following letters to customize the fields
shown in the following table:
• “p” indicates “pattern”: the blinking pattern of the LED
• “c” indicates “color”: the color of the LED
• “r” indicates “red”: a red-colored LED
• “g” stands for “green”: a green-colored LED

Cisco SPA303 Specifications

General

Display	Monochrome LCD
Lines	3
Speakerphone	Yes
Headset Jack	Yes (2.5 mm)
Handset	Yes
Ethernet Ports	2 x 10/100 Mbps
Protocol	SIP
Power	Power over Ethernet (PoE) or AC adapter
Audio Codec Support	G.711, G.729
QoS	802.1p/q
