Customizing Cisco SPA and Wireless IP Phones
Enabling Call Features
Cisco Small Business SPA300 Series, SPA500 Series, and WIP310 IP Phone Administration Guide 61
3
STEP 4 Under Multiple Paging Group Parameters, enter the paging commands into the
Group Paging Script field. The syntax is as follows:
pggrp=ip-address:port;[name=xxx;]num=xxx;[listen={yes|no}]];
Where:
• IP address: Multicast IP address of the phone that will listen for and receive
pages.
• port: Port on which to page; you must use different ports for each paging
group. All phones in the same paging group must use the same port
number.
• name (optional): The name of the paging group.
• num: The number users will dial to access the paging group; must be unique
to the group.
• listen: If the phone being configured is a listening member of the page
group. A phone can be a listening member of a maximum of two groups. If
no value is entered, the default is to not listen as a member of this group.
STEP 5 Click Submit All Changes.
Configuration Example
The following example sets up four paging groups:
All
,
Sales
,
Support
, and
Engineering
. Users will press 801 to send pages to all phones, 802 to send pages
to phones configured as part of the Sales group, 803 to send pages to phones
configured as part of the Support group, and 804 to send pages to phones
configured as part of the Engineering group.
A phone that is configured with this example is a listening member of the “All” and
“Sales” paging groups. That phone will automatically receive pages sent to those
two paging groups.
For each Sales phone, enter the following in the Phone > Multiple Paging Groups
Parameters > Group Paging Script field:
pggrp=224.123.123.121:43210;name=All; num=801;listen=yes;
pggrp=224.123.123.121:43211;name=Sales;num=802; listen=yes;
pggrp=224.123.123.121:43212;name=Support;num=803;
pggrp=224.123.123.121:43213;name=Engineering;num=804;
