OPERATING THE TRANSCEIVER
DATA OPTIONS
ENVOY® TRANSCEIVER GETTING STARTED GUIDE 99
RM50e HF Data Modem
The RM50e HF Data Modem provides data communications. It
may also be used to provide high-grade AES-256 digital
encryption. It may be used with any data-capable Codan HF
transceiver. It must be used in conjunction with the RC50-C HF
Email software. The data modem is capable of high-speed data
transfer at speeds of up to 9600 bit/s using STANAG 4539
waveforms. The data modem also supports MIL-STD-188-110A/B
(including Appendix F), STANAG 4285, STANAG 4529, and
STANAG 4415 waveforms.
NOTE: When a data application is connected, an icon
appears in the status bar of the channel screen ( ).
NOTE: The RM50e HF Data Modem may only be used via
the RFU GP port connector.
Related links:
Using encryption on page 103
Typical RM50e data station
A typical RM50e data station comprises:
• any data-capable Codan HF transceiver
• an antenna system
• an appropriate 12 V DC power supply
• an RM50e HF Data Modem, selected as a peripheral device
• a computer with RC50-C HF Email software
