INSTALLING THE TRANSCEIVER
OVERVIEW OF FIXED STATIONS
ENVOY® TRANSCEIVER GETTING STARTED GUIDE 185
Cables in a fixed station
NOTE: Cable 08-06022-001 is a 6 m cable only. Cable
08-01503-006 is a 6 m cable and is available in a
number of shorter and longer lengths.
Mounting a fixed Envoy® station
A fixed Envoy® station uses a 2230 Desk Console. For general
guidance on suitable locations for equipment and installing the
fixed station see the reference material on the enclosed CD.
RFU and transceiver supply
The RFU and the transceiver supply are self-contained and are
usually stacked loosely. If you want to mount the RFU and/or the
transceiver supply, contact your Codan representative to obtain a
rack-mounting unit or the appropriate mounting cradles.
CAUTION: If you are mounting an RFU in a cradle, do not fit
rubber feet to the bottom of the RFU.
NOTE: If you are transferring a mobile station to a fixed
station, and you are not mounting the RFU in a
cradle, rubber feet can be fitted to the bottom of the
RFU. The rubber feet are available from Codan
(Codan part number 30-11208-000).
Table 10: Cables for a typical fixed Envoy® station
Cable Symbol Part number
Cable between RFU and 2230 Desk Console 08-07205-xxx
Handset and speaker connector and cable
(optional)
08-06022-001
Coaxial cable between RFU and antenna 08-01503-006
