INSTALLING THE TRANSCEIVER
OVERVIEW OF FIXED STATIONS
184 ENVOY® TRANSCEIVER GETTING STARTED GUIDE
Figure 47: Typical fixed station
NOTE: A range of ancillary equipment may be connected to
the Envoy transceiver using the 6-way and GP port
connectors at the rear of the RFU.
RF Unit
™
Type 2210
Serial No.
antenna control
antenna
battery
RFU
10-way
connector
GP port
connector
6-way
connector
power supply
AC mains
tuner
(optional)
broadband
antenna
Desk Console
™
desk console
08-07205-00x
08-03255
08-01503-00x
08-05627-00x
3020 Transceiver Supply
