INSTALLING THE TRANSCEIVER
OVERVIEW OF FIXED STATIONS
188 ENVOY® TRANSCEIVER GETTING STARTED GUIDE
To connect the tuner to the RFU:
1 Connect the plug at the end of the coaxial cable from the
tuner to the socket at the end of the cable lead from the
RFU, then secure the locking ring tightly into position.
1 Connect the plug at the end of the control cable from the
tuner to the socket at the end of the cable lead from the
RFU, then secure the locking ring tightly into position.
1 Connect the antenna to the antenna connector on the tuner,
then secure it tightly into position.
Connecting the transceiver supply
To connect the transceiver to the transceiver supply:
1 Connect the DC output from the transceiver supply to the
plug at the end of the 12 V cable lead from the RFU.
1 Connect the transceiver supply to the AC mains supply.
Earthing the transceiver
For information on earthing a fixed station, see the Installation
section in the Reference Manual.
Earthing the antenna
For information on earthing a fixed antenna, see the Installation
section in the Reference Manual.
