OPERATING THE TRANSCEIVER
DATA OPTIONS
86 ENVOY® TRANSCEIVER GETTING STARTED GUIDE
Data options
2.4 kbit/s Data Modem
NOTE: The 2.4 kbit/s Data Modem option must be enabled
in your Envoy X2 transceiver.
This internal data modem provides an extremely robust,
field-proven HF waveform that is interoperable with Codan’s
proprietary 3012 protocol and 3212 HF Data Modem (operating in
compatibility mode).
NOTE: When a data application is connected, an icon
appears in the status bar of the channel screen ( ).
This modem can be used with ALE and Selcall call systems. Voice
links may be established first, then a data exchange may be
performed.
The modem is controlled by the connected computer using the
UUPlus©/Codan Chat© HF data applications. Email is sent and
received via your chosen email client, for example Microsoft®
Office Outlook®. For information on using UUPlus©/Codan
Chat©, please see the documentation provided with the product.
Typical 2.4 kbit/s data station
A typical data station comprises:
• an Envoy X2 transceiver with the 2.4 kbit/s Data Modem
option enabled (Codan part number 15-10559)
• a suitable 12 V DC power supply
• an antenna system
• a PC running UUPlus©/Codan Chat© or suitable terminal
program
• appropriate connecting cables
