NAVIGATING THE MENU STRUCTURE
NAVIGATING THE MENU STRUCTURE
144 ENVOY® TRANSCEIVER GETTING STARTED GUIDE
Navigating the menu structure
The menu structure comprises a main menu and a series of
submenus that are accessed via the main menu. Navigation keys
enable you to highlight an icon, then press OK to select that menu.
You can continue drilling down through the menu structure in this
way. At the lowest level of the menu structure there is either an
input/view screen, or a list of entries.
Navigation is available when the navigation indicator is shown in
the menu bar at the bottom of the screen.
Figure 32: Navigation indicator showing navigation keys
that may be used
NOTE: This icon alternates with operational status icons that
indicate when the RFU is busy with an activity from
a control point in a multiple control point system.
To navigate the menu structure:
1 To move down through the menu structure:
• Press , , or to highlight the icon that you
want to select.
The name of the icon appears in the title bar of the
screen.
NOTE: If the right-most icon is highlighted
when you press , the highlight
wraps to the first icon in the next row
of icons.
navigation
indicator
( keys may be used)
