INSTALLING THE TRANSCEIVER
OVERVIEW OF FIXED STATIONS
186 ENVOY® TRANSCEIVER GETTING STARTED GUIDE
Rack-mounting unit
A rack-mounting unit consists of a 19 inch rack tray. It can be used
to mount your fixed station with either a desk console or the
handset and cradle.
Connecting a fixed Envoy® station
NOTE: A typical fixed station is shown in Figure 47.
To connect a fixed station:
1 Do one of the following:
• Connect cable 08-07205-00x between the
Transceiver connector on the 2230 Desk Console
and the 10-way plug on the flying lead from the
RFU, securing the locking rings tightly into position.
CAUTION: If the desk console is connected to the
RFU via cable 08-07205-00x, ensure
that an Ethernet cable is not connected
to the RJ45 connector on the rear of
the desk console.
• Connect cable 08-07215-001 between the Ethernet
connector on the 2230 Desk Console, or an optional
switch/router, and the 10-way plug on the flying lead
from the RFU, securing the locking ring tightly into
position.
CAUTION: If the desk console is connected to the
RFU via an Ethernet cable and cable
08-07215-001, ensure that cable
08-07205-00x is not connected to the
8-way connector ( ) on the rear of the
desk console.
