INSTALLING THE TRANSCEIVER
OVERVIEW OF MOBILE STATIONS
180 ENVOY® TRANSCEIVER GETTING STARTED GUIDE
1 Place the RFU into the cradle and push it under the tabs at
the rear of the cradle, then hold the clamp against the front
of the RFU.
1 Rotate the key clockwise, then push the key toward the base
of the cradle to lock the RFU into position.
Connecting a mobile Envoy® station
NOTE: A typical mobile station is shown in Figure 46.
To connect a mobile station:
1 Connect the cable (Codan part number 08-06022-001) from
the handset and speaker connector to the 10-way plug on the
cable lead from the RFU, then secure the locking ring
tightly into position.
1 Connect the plug of the handset cable to the socket on the
handset and speaker connector, then secure the locking ring
tightly into position.
1 Connect the plug at the end of the speaker cable to the
socket on the handset and speaker connector, then secure the
cable by pushing it into the slot on the side of the connector.
1 Connect the plug at the end of the cable (Codan part
number 08-01503-00x) to the socket at the end of the cable
lead from the RFU, then secure the locking ring tightly into
position.
1 Connect the plug at the opposite end of the cable (Codan
part number 08-01503-00x) to the socket located at the base
of the antenna, then secure the locking ring tightly into
position.
