ENVOY® TRANSCEIVER GETTING STARTED GUIDE 189
D
Specifications
Table 11: Specifications
Item Specification
Frequency range Transmit: 1.6 MHz to 30 MHz
Receive: 0.25 MHz to 30 MHz
Channel capacity
(single or
two-frequency
simplex channels)
X1: 100 (International)
400 (Australia)
X2: 1 000
Operating modes Single sideband (J3E) USB and LSB or switched
USB/LSB, AM (A3E Rx, H3E Tx),
CW/LMCW/UMCW (J1A, A1A)
Environment Ambient temperature: −30°C to +60°C
(–22°F to 140°F)
Relative humidity: 95%
Derate upper ambient temperature by 1°C (1.8°F) per
330 m (360 yd) above sea level
Cooling Convection or fan (Option F)
