COMPLIANCE
EMC AND SAFETY NOTICES
200 ENVOY® TRANSCEIVER GETTING STARTED GUIDE
Earth symbols
RF earth connection points are provided on the Envoy transceiver
and 3020 Transceiver Supply. A protective earth is provided in the
AC mains wiring of the 3020 Transceiver Supply. This protective
earth must be connected at the AC mains supply outlet. The
symbols shown below are used to identify the earths on the
equipment.
Table 12: Earth symbols
Symbol Meaning
Chassis earth
Protective earth
