Codan Envoy Getting Started Guide
4
of 1
of 1 rating
219 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
N
AVIGATING
THE
MENU
STRUCTURE
S
ELECTING
A
FUNCTION
FROM
THE
MENU
BAR
154
E
NVOY
® T
RANSCEIVER
G
ETTING
S
TARTED
G
UIDE
1
If a pop-up of
available functions i
s shown:
•
Press
or
to scroll to the
function that you want
to select.
•P
r
e
s
s
(
Select
).
The function is performed.
1
If you want to close t
he pop-up and not
perform any of the
functions, press the opposite software key (typical
ly
Close
).
165
167
Table of Contents
Default Chapter
3
Table of Contents
3
Introduction
14
Overview of this Guide
14
The 2220 Handset
15
Figure 1: 2220 Handset
15
The 2221 Handset
17
Figure 2: 2221 Handset
17
The 2230 Desk Console
19
Figure 3: 2230 Desk Console
19
Keypad
20
Table 1: Keys and Their Function
20
Standards and Icons
24
Using the Wizard
25
Overview of the Wizard
26
Figure 4: Steps in the Wizard
26
Using the Wizard
28
Figure 5: Wizard Startup Screen
28
Selecting a Language
29
Setting the Time and Date
29
Setting the Types of Connections between Modules
30
Adding a Channel
31
Adding Channels to a Scan Table
33
Entering a Self Address
33
Adding a Contact
34
Adding a Simple Call
35
Adding a Message Call
36
Adding a Phone Call
38
Completing the Contact
38
Selecting an Antenna
39
Selecting a Peripheral Device
40
Switching the Transceiver on and off
42
Switching on the Transceiver
42
Switching off the Transceiver
42
The Channel Screen
43
Figure 6: Channel Screen
44
Figure 7: System Lock and Connected Data Application Icons
45
Figure 8: Scanning Screen
46
Selecting a Channel
47
Selecting a Channel from a Channel Group
48
Scanning Channels
51
Switching Scanning on or off
52
Pausing Scanning
52
Muting the Transceiver
54
Switching Mute on or off
54
Selecting the Mute Type
55
Using the Microphone
56
Setting the Basics
57
Setting the Time and Date
57
Setting the Brightness of the Display
58
Calling
59
Making a Call to a Contact
60
Making a Call from the Call History
61
Making a Call from the Emergency Key
63
Making a Selective Call
64
Figure 9: Chain Call
64
Making a Message Call
66
Receiving a Call
70
Figure 10: Incoming Call Pop-Up
71
Viewing Missed Calls
72
Figure 11: Missed Call Pop-Up for a Single Call
72
Figure 12: Missed Call Pop-Up for Multiple Calls
72
Figure 13: Example of a Missed Call Icon in the Status Bar
73
Table 2: Missed Call Icons that May be Shown in the Status Bar of
73
Making a Call When Multiple Control Points Are Connected to the same RFU
75
Figure 14: Calling Information When Multiple Control Points
75
Using Digital Voice
77
Overview of Digital Voice Options
77
Table 3: Digital Voice Options
77
Digital Voice Rate
78
Table 4: Digital Voice Rates
79
Digital Voice Mute
80
Figure 15: Channel Screen Showing the Digital Voice Rate
80
Switching the Digital Voice Feature on or off
81
Figure 16: Digital Voice Mute Indicator
81
Figure 17: Channel Screen Showing On/Off Status for a DV Option (Without Encryption)
82
Figure 18: Channel Screen Showing Transmit/Receive Status for a DV Option (Without Encryption)
82
Figure 19: Channel Screen Showing Secure/Clear Status for All
83
Selecting the Digital Voice Rate
84
Figure 20: Channel Screen Showing Transmit/Receive Status for All Encrypted Digital Voice
84
Selecting Digital Voice Mute
85
Using GPS
87
Saving Your Current GPS Position as a Waypoint
87
Selecting a Waypoint
87
Updating a Waypoint from the Call History
88
Updating a Waypoint from a Contact
89
Adding a Waypoint
91
Finding a Waypoint
93
Viewing the Details of a Waypoint
94
Viewing GPS Information
95
Table 5: GPS Information
97
Data Options
98
2.4 Kbit/S Data Modem
98
Typical 2.4 Kbit/S Data Station
98
Figure 21: Envoy X2 Transceiver with 2.4 Kbit/S Data Modem
99
Using the 2.4 Kbit/S Data Station
100
MIL/STANAG 2G Data
104
Table 6: Status of the 2.4 Kbit/S Data Modem
104
Typical MIL/STANAG 2G Data Station
105
Figure 22: Envoy X2 Transceiver with MIL/STANAG 2G Data
106
Figure 23: Envoy X2 Transceiver with MIL/STANAG 2G Data
107
Figure 24: Envoy X2 Transceiver with MIL/STANAG 2G Data
108
Sending Email Via RC50-C
109
Figure 25: Transmit and Receive Screens During a MIL/STANAG 2G Data Call
110
Rm50E HF Data Modem
111
Typical Rm50E Data Station
111
Figure 26: Envoy X2 Transceiver with Rm50E HF Data Modem
112
Sending Email Via RC50-C
113
Figure 27: Transmit and Receive Screens During an Rm50E
114
Using Encryption
115
Switching the Secure Feature on or off
115
Entering a PIN for a Secure Session
120
Selecting a Secure Key
121
Changing the Privacy Code
122
Adding a Secure Key
123
Using a Crosspatch
126
Overview of the 3031 Crosspatch
126
Figure 28: Crosspatch Status
127
Changing the Operating Mode of the Crosspatch
128
Using Codan Convoy
129
Overview of Codan Convoy
129
Using an External Power Amplifier
130
Overview of the 3061 & 3062 Power Amplifiers
130
Inspecting the Status of the Power Amplifier
130
Displaying the Power Amplifier Status in the Status Areas
131
Viewing the Power Amplifier Status in the HPA Status Screen
131
Viewing the Fault State of the Power Amplifier
132
Clearing the Fault State of the Power Amplifier
132
Checking the Power Amplifier's Control Board
133
Firmware Version
133
Upgrading the Transceiver Via a USB Stick
134
Using GPS Plotter
137
Overview of GPS Plotter
137
Using VCOM Services
138
Adding a Contact
142
Adding a Simple Call
143
Adding a Message Call
144
Adding a Phone Call
146
Completing the Contact
147
Or Last Heard Log
150
Figure 29: Call Log, Call History, and Last Heard Log
150
Adding a Contact from the Call Log, Call History
152
Navigating the Menu Structure
153
Appendix A Navigating the Menu Structure
154
The Basic Menu Structure
154
Figure 30: Typical Menu Screen
154
Figure 31: Menu Structure (User Level, Basic View)
155
Navigating the Menu Structure
156
Figure 32: Navigation Indicator Showing Navigation Keys that
156
Overview of Basic and Advanced Views
158
Basic View
158
Advanced View
158
Figure 33: Basic View (no Advanced View Indicator)
158
Switching between Basic and Advanced Views
159
Figure 34: Advanced View
159
Finding a Word or Value
161
Figure 35: Find Function
161
Selecting an Icon
164
Figure 36: Highlighted Icon
164
Selecting a Function from the Menu Bar
165
Figure 37: Functions on the Menu Bar
165
Entering Text in a Field
167
Figure 38: Example of an Editable Text Field
167
Figure 39: Character-Entry Mode Indicator
168
Table 7: Character-Entry Mode
168
Entering a Special Character (2220/2230)
169
Entering Text with the 2221 Handset
170
Entering Text with a USB Keyboard
171
Editing Text with a USB Keyboard
172
Entering a Special Character with a USB Keyboard
174
Table 8: USB Keyboard Special Keys
174
Selecting a Value from a List
176
Figure 40: List of Entries, with and Without Focus
176
Selecting/Deselecting a Check Box
177
Figure 41: Entry with a Check Box
177
Moving a Slider
178
Figure 42: a Slider Value
178
Changing the Order of Items in a List
179
Saving Your Changes
180
Figure 43: Screen that Has Changes to be Saved
180
Structure of Information
181
Structure of User Information
182
Figure 44: Basic Structure of Information in the Envoy Transceiver
182
Structure of Contact and Call Information
184
Figure 45: Structure of Call Information for a Contact in the Envoy Transceiver
184
Appendix B Structure of Information
187
Installing the Transceiver
187
Appendix C Installing the Transceiver
188
Overview of Mobile Stations
188
Figure 46: Typical Mobile Station
189
Cables in a Mobile Station
190
Mounting a Mobile Envoy® Station
190
Mounting the Handset Cradle
190
Table 9: Cables for a Typical Mobile Envoy® Station
190
Mounting the Speaker
191
Mounting the Handset and Speaker Connector
191
Mounting the RFU
191
Connecting a Mobile Envoy® Station
192
Connecting the Control Cable to an Automatic Tuning Antenna
193
Connecting the Power Supply
193
Earthing the Transceiver
194
Earthing the Antenna
194
Overview of Fixed Stations
195
Figure 47: Typical Fixed Station
196
Cables in a Fixed Station
197
Mounting a Fixed Envoy® Station
197
RFU and Transceiver Supply
197
Table 10: Cables for a Typical Fixed Envoy® Station
197
Rack-Mounting Unit
198
Connecting a Fixed Envoy® Station
198
Connecting an Automatic Tuner to the RFU and Antenna (Optional)
199
Connecting the Transceiver Supply
200
Earthing the Antenna
200
Earthing the Transceiver
200
Appendix D Specifications
201
Table 11: Specifications
201
Appendix E about this Issue
203
Appendix F Compliance
206
Overview
206
European Radio Equipment Directive 2014/53/EU
207
Product Marking and Labelling
207
Radiation Safety (EU Installations Only)
207
Declaration of Conformity
208
Protection of the Radio Spectrum
208
EMC and Safety Notices
210
Radiation Safety (Non-EU Installations)
210
Emc
210
Electrical Safety
211
Earth Symbols
212
FCC Compliance
213
FCC Part 90 Certification
213
FCC Part 15 Compliance
213
RCM Approval
214
