80 • SMP Gateway User Manual
Collapse the Slave Protocol branch and expand Connections, and then select TCP/IP
Slaves.
Under Name, type the TCP/IP slave's name. For example, you can name it
Interconnections.
Under Port, type 6655.
Note: Port 6655 is recommended for Interconnections. You can use another port,
but make sure you specify the same in the master SMP Gateway’s
configuration.
Configure the connection usage:
Click the Connection Usage branch.
In the right pane, under Slave Connection Usage, you will see the Cedar Creek Slave
you created in the previous steps. Scroll to the right and select the checkbox under the
TCP/IP slave's name (in the example, the name is Interconnection).
Save the configuration file and close SMP Config.
Send the configuration file to the SMP Gateway using SMP Manager (see “Updating the
Configuration File” on page 225).
Restart the SMP Gateway.
