DGS-3100 Series Gigabit Stackable Managed Switch CLI Manual
201
34
ACCESS CONTROL LIST COMMANDS
The Access Control List commands in the Command Line Interface (CLI) are listed (along with the
appropriate parameters) in the following table.
Command Parameter
create access_profile
(for Ethernet)
profile_id <value 1-15> [ethernet {vlan | source_mac <macmask 000000000000-
ffffffffffff> |destination_mac <macmask 000000000000-ffffffffffff> | 802.1p |
ethernet_type}]
create access_profile
(for IP)
profile_id <value 1–15> ip [ icmp { type | code } | igmp { type } | tcp
{ src_port_mask < hex 0x0–0xffff > | dst_port_msk <hex 0x0–0xffff> |
flag_mask }}{+ | –} {urg | ack | psh | rst | syn | fin }} | udp { src_port_mask < hex
0x0–0xffff > | dst_port_msk <hex 0x0–0xffff> } ] { source_ip_mask <netmask> |
destination_ip_mask <netmask> | dscp }
config access_profile
(for Ethernet)
profile_id <value 1-15> [add access_id [auto assign | <value 1-240>] [Ethernet
{vlan <vlan_name 32> | source_mac <macaddr 000000000000-ffffffffffff> |
destination_mac <macaddr 000000000000-ffffffffffff> | 802.1p <value 0-7> |
ethernet_type <hex 0x0-0xffff>} ports <portlist> [permit {replace_priority <value
0-7> | replace_dscp <value 0-63> | rate_limit <value 64-1000000>} | deny]
{time_range <range_name 32>}
config access_profile
profile_id <value 1-15> [add access_id [auto assign | <value 1-240>] [ip
{source_ip <ipaddr> | destination_ip <ipaddr> | dscp <value 0-63> | [icmp {type
<value 0-255> code <value 0-255>} | igmp {type <value 0–255>} | tcp {src_port
<value 0-65535> | dst_port <value 0-65535> | flag flag {+ | –} {urg | ack | psh |
rst | syn | fin }} | udp {src_port <value 0-65535> | dst_port <value 0–65535>}]}
ports <portlist> [permit {replace_priority <value 0-7> | replace_dscp <value 0–
63> | rate_limit <value 64-1000000>} | deny] {time_range <range_name 32>}
config access_profile profile_id <value 1-15> delete access_id <value 1-240>
delete access_profile profile_id <value 1-15>
show access_profile {profile_id <value 1-15>}
config time–range
<range_name 32> [hours start_time <time hh:mm> end_time <time hh:mm>
weekdays <daylist> | delete]
show time–range
Each command is listed in detail, as follows:
create access_profile (for Ethernet)
Purpose To create an access profile on the Switch by examining the Ethernet
part of the packet header. Masks entered are combined with the
values the Switch finds in the specified frame header fields. Specific
values for the rules are entered using the config access_profile
command, below.
Syntax
create access_profile profile_id <value 1-15> [ethernet {vlan |
source_mac <macmask 00:00:00:00:00:00-ff:ff:ff:ff:ff:ff >
|destination_mac <macmask 00:00:00:00:00:00-ff;ff:ff:ff:ff:ff > |
