DGS-3100 Series Gigabit Stackable Managed Switch CLI Manual
90
Example usage:
To display the current scheduling configuration:
DGS3100# show scheduling
QOS Output Scheduling
MAX. Packet
---------------------------
Class-0 1
Class-1 2
Class-2 3
Class-3 4
DGS3100#
config bandwidth_control
Purpose To configure bandwidth control on the Switch.
Syntax
config bandwidth control [<portlist> | all] {rx_rate [no_limit |
<value 3500-1000000>] | tx_rate [no_limit | <value 64-1000000>]}
Description The config bandwidth_control command defines bandwidth
control.
Parameters portlist - A port or range of ports to be configured.
all - Specifies that the config bandwidth_control command applies
to all ports on the Switch.
rx_rate - Enables ingress rate limiting
• no_limit – Indicates no limit is defined.
• <value 3500–1000000>] – Indicates a range between 3500-
100000 kbps.
tx_rate – Enables egress rate limiting.
• no_limit – Indicates no limit is defined.
• <value 64-1000000>] – Indicates a range between 64-
1000000 kbps.
Restrictions None.
Example usage:
To configure bandwidth control configuration::
DGS3100# config bandwidth_control all rx_rate no_limit
Success.
DGS3100#
show bandwidth_control
Purpose To display bandwidth control settings on the Switch.

D-Link DGS-3100 SERIES Specifications

General

Type	Managed
Layer	Layer 2+
Ports	10/100/1000BASE-T
SFP Ports	2 or 4 (depends on the model)
Additional SFP Ports	No
VLANs	Yes
Stacking	Yes, Physical Stacking
QoS	Yes
Jumbo Frame Support	Up to 9K bytes
Management	Web-based
Operating Temperature	0°C to 40°C
Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
Model	DGS-3100 SERIES
Storage Temperature	-40°C to 70°C
