DGS-3100 Series Gigabit Stackable Managed Switch CLI Manual
86
11
BROADCAST STORM CONTROL COMMANDS
The Broadcast Storm Control commands in the Command Line Interface (CLI) are listed (along with the
appropriate parameters) in the following table.
Command Parameter
config traffic control
{[<portlist> | all] state [enable | disable] | storm_type [broadcast | multicast
_broadcast | dlf_ multicast _broadcast ] threshold <int 3500-1000000>}
show traffic control {ports <portlist>}
Each command is listed in detail, as follows:
config traffic control
Purpose To configure broadcast / multicast / unknown unicast traffic control.
Syntax
config traffic control {[<portlist> | all] state [enable | disable] |
storm_type [broadcast | broadcast_multicast |
broadcast_multicast_dlf ] threshold <int 3500-1000000>}
Description The config traffic control command configures broadcast,
multicast and unknown unicast storm control.
Parameters <portlist> - A port or range of ports to be configured.
all − Specifies all ports on the Switch are to be configured.
storm_type – The type of broadcast storm for which to configure the
traffic control. The options are:
• broadcast – Enables broadcast storm control only.
• multicast_broadcast – Enables broadcast and multicast
storm control.
• dlf_ multicast_broadcast - Enables broadcast, multicast and
unknown unicast storm control.
<int 3500-1000000> − The upper threshold at which the specified
traffic control is switched on. The value is the number of
broadcast/multicast/dlf packets, in Kbps, received by the Switch that
will trigger the storm traffic control measures. The value ranges in
size from 3500 to 1000000 Kbps.
Restrictions Only administrator or operator-level users can issue this command.
Example usage:
To configure traffic control and enable broadcast storm control system wide:
DGS3100# config traffic control all state enable threshold 15000
storm_type multicast_broadcast
Success.
DGS3100#
