12 • Genie Nano Specifications Nano Series GigE Vision Camera
Multicast
Programming support for multicasting images (requires Multicast host support: refer to
the SDK documentation – if supported)
Action Command
Programmable for up to 2 GenICam Action Commands (requires host support: refer to
the SDK documentation – if supported)
Test image Internal generator with choice of static and shifting patterns
User settings Select factory default or either of two user saved camera configurations
TurboDrive Technology Supported with 8-bit or 16-bit buffer format (see Sapera 8.10 release notes)
Not supported with RGB output firmware for any Nano model due to limitations of
camera resources.
Back Focal Distance
17.52 mm (C-mount models), 12.52 mm (CS-mount models)
12 mm (model NanoXL)
Mechanical Interface
Camera (L x H x W)
see Mechanical Specifications
21.2 mm x 29 mm x 44 mm (without lens mount or Ethernet connector)
38.9 mm x 29 mm x 44 mm (with C-mount and Ethernet connector)
23.7 mm x 59 mm x 59 mm (NanoXL without Ethernet connector)
38.3 mm x 59 mm x 59 mm (NanoXL with Ethernet connector)
Mass (approximate value due to
sensor variations)
~ 46g (C-mount with no lens)
~ 163g — model NanoXL
Power connector via the 10-pin I/O connector, or RJ45 in PoE mode
Ethernet connector RJ45
Electrical Interface
Input Voltage Supports the Power Over Ethernet standard. (PoE Class 3 as per IEEE 802.3af)
Alternatively via the Auxiliary connector:
+12 to +36 Volts DC recommended (+10%/- 10%)
+10 to +56 Volts DC (Absolute min/max Range)
Inputs/Outputs
Default models have 2 Inputs and 2 Outputs
Optional models have 1 Input and 3 Outputs
XL models have 2 Inputs and 3 Outputs
Power Dissipation (typical)
Nano: PoE Class 2
From 3.8W to 4.9W dependent on Nano model and power supply voltage
NanoXL: PoE Class 3 (Up to 7W) or external 24Volt power (6.6W)
Data Output Gigabit Ethernet 1000Mbps (10/100 Mbps are not supported) 115 MB/sec max.
Ethernet Option supported PAUSE Frame support (as per IEEE 802.3x)
Data and Control GigE Vision 1.2 compliant
Environmental Conditions
Operating Temperature
(at camera front plate)
All Models: -20°C to +65°C (-4°F to +149°F)
Model C4900 Exception: -20°C to +50°C (-4°F to +122°F)
Temperature range specification based on an auxiliary input voltage of +20 to +36Vdc
or PoE.
Any metallic camera mounting provides heat-sinking therefor reducing the internal
temperature.
Operating Relative Humidity 10% to 80% non-condensing
Storage
-40°C to +80°C (-4°F to +176°F) temperature at 20% to 80% non-condensing
relative humidity
Conformity CE, FCC, KC, GenICam, GigE Vision, IP30, IEEE 802.3af (PoE)
