Nano Series GigE Vision Camera Sony Sensor Models • 27
Image Flip Support Yes, In-Sensor, Vertical and Horizontal
Multi-ROI Support Yes, in-sensor, up to 16 ROI (mutually exclusive with binning)
On-Board Image Memory 90MB
Output Dynamic Range (dB) 68.3 dB (in 10-Bit Pixel Format)
SNR (dB) 43.9 dB (in 10-Bit Pixel Format)
*TurboDrive internal limitation of 250MB/sec
Notes:
** Limited to the Genie Nano Architecture:
• ~250MB/sec Sustained into the TurboDrive Engine
• Additional note: This transfer was achieved using 1500 Byte Packet Size.
*** Actual Exposure Time:
• The actual internal minimum exposure may be different than what is programmed. Use the
feature “exposureTimeActual” from the Sensor Control category to read back the actual
sensor exposure.
Firmware Files for 1920, 1940
The latest firmware files for all Nano models are available on the Teledyne DALSA support web site:
http://www.teledynedalsa.com/imaging/support/downloads/firmware/
The firmware files for these models are listed below. The xx denotes the build number.
M1920
• Standard
“Genie_Nano_Sony_IMX249-2M_Mono_STD_Firmware_3CA18.xx.cbf”
C1920
• Bayer Output
“Genie_Nano_Sony_IMX249-2M_Bayer_STD_Firmware_4CA18.xx.cbf”
• RGB Output
“Genie_Nano_Sony_IMX249-2M_RGB_Output_Firmware_4CA18.xx.cbf”
M1940
• Standard
“Genie_Nano_Sony_IMX174-2M_Mono_STD_Firmware_1CA18.xx.cbf”
C1940
• Bayer Output
“Genie_Nano_Sony_IMX174-2M_Bayer_STD_Firmware_2CA18.xx.cbf”
• RGB Output
“Genie_Nano_Sony_IMX174-2M_RGB_Output_Firmware_4CA18.xx.cbf”
