Nano Series GigE Vision Camera On-Semi Sensor Models • 65
On-Semi Sensor Models
Genie Nano cameras utilizing On-Semi sensors (monochrome and color) are described.
Specifications: M640, M640-NIR, C640
Supported Features M640, M640-NIR C640
Resolution 672 x 512
Sensor OnSemi Python300 P1 (0.3M)
Pixel Size 4.8 µm x 4.8 µm
Shutter type Full frame electronic global shutter function
Full Well charge 10ke (max)
Firmware option
(Field programmable)
Standard Design
Monochrome
(factory default)
Standard Design
Bayer
(factory default)
RGB-Output
Design
Max. Internal Frame Rate
862 fps at 640 x 480 (Fast Readout Enable)
603 fps at 640 x 480 (Normal Readout Enable)
Maximum Sustained Frame Rate
Output (with TurboDrive v1)*
720 fps (8-bit)
360 fps (10-bit)
N/A
Maximum Sustained Frame Rate
Output (without TurboDrive)
345 fps (8-bit)
172 fps (10-bit)
86 fps (RGBA)
115 fps (RGB)
172 fps (Yuv422)
345 fps (8-bit mono)
Pixel Data Formats
Mono 8-bit
Mono 10-bit
Bayer 8-Bit
Bayer 10-Bit
RGBA 32-bit
RGB 24-bit
Yuv422 16-bit
Mono 8-bit
Trigger to Exposure Minimum delay
(Synchronous Exposure Alignment)
4 µs if exposureAlignment = Synchronous With No Overlap
between the new exposure and the previous readout
26.2 µs if exposureAlignment = Synchronous With Overlap
between the new exposure and the previous readout
Trigger to Exposure Minimum delay
(Reset Exposure Alignment)
4 µs
Trigger to Exposure Start jitter (best
case with Synchronous Exposure
Alignment)
Up to 1 line time
Trigger to Exposure Start jitter
(Reset Exposure Alignment) †
0 µs
Exposure Time Minimum
(see “exposureTimeActual” in
Sensor Control)
34 µs
(increment steps of 1µs)
Min. Time from End of Exposure to
Start of Next Exposure (second
frame)
19 µs – Normal Readout
18 µs – Fast Readout
Horizontal Line Time:
3.3 µs – Normal Readout
2.28 µs – Fast Readout
