Dalsa Genie Nano Series User Manual

Nano Series GigE Vision Camera Operational Reference • 129
I/O Control Feature Descriptions
The following table describes these features along with their view attribute and minimum camera
firmware version required. Additionally the Device Version column will indicate which parameter is
a member of the DALSA Features Naming Convention (indicated by DFNC), versus the GenICam
Standard Features Naming Convention (SFNC tag is not shown).
The Device Version number represents the camera software functional group, not a firmware
revision number. As Genie Nano capabilities evolve the device version tag will increase, therefore
identifying the supported function package. New features for a major device version release will be
indicated by green text for easy identification.
Display Name Feature & Values Description
Device
Version
& View
Trigger Selector TriggerSelector Selects which type of trigger to configure with the
various Trigger features.
1.00
Beginner
Single Frame Trigger(Start) FrameStart Selects a trigger starting the capture of a single
frame. Frame size is determined by image format
feature “Height”.
MultiFrame Trigger(Start) FrameBurstStart Selects a trigger to capture multiple frames. The
number of frames is specified by the
“triggerFrameCount” feature.
AcquisitionStart
Trigger(Start)
AcquisitionStart Enables the selection of a trigger source that starts
the Acquisition of one or many frames. (Ver.1.05)
Trigger Mode TriggerMode Controls the enable state of the selected trigger.
1.00
Beginner
Off Off The selected trigger is turned off.
On On The selected trigger is turned active.
Trigger Frames Count triggerFrameCount Sets the total number of frames to acquire when a
valid trigger is received. This feature is available
when Trigger Selector = MultiFrame Trigger(Start).
1.00
DFNC
Beginner
Software Trigger TriggerSoftware Generate a software command internal trigger
immediately no matter what the TriggerSource
feature is set to.
1.00
Beginner
Trigger Source TriggerSource Specifies the internal signal or physical input line to
use as the trigger source. The selected trigger
must have its TriggerMode set to ON.
See Input Signals Electrical Specifications.
1.00
Beginner
Line 1 Line1 Select Line 1 (and associated I/O control block) to
use as the external trigger source. See
LineSelector feature for complete list.
Line 2 Line2 Select Line 2 (and associated I/O control block) to
use as the external trigger source. See
LineSelector feature for complete list.
Software Software The trigger command source is only generated by
software using the Trigger Software command.
Action 1 Action1 Select the GigEVision Action Command 1 as the
internal trigger source. This is a broadcast
command that multiple devices can respond to
simultaneously. (Ver. 1.03)
Action 2 Action2 Select the GigEVision Action Command 2 as the
internal trigger source. This is a broadcast
command that multiple devices can respond to
simultaneously. (Ver. 1.05)
Timestamp Modulo Event timestampModuloEvent Select the timestamp modulo event as the internal
trigger source. (Ver. 1.03)
Timer1End Event Timer1End Select the TimerEnd Event as the internal trigger
source.
