60 • Sony Sensor Models Nano Series GigE Vision Camera
Specifications: M4030, C4030
Supported Features M4030 C4030
Resolution 4112 x 2176
Sensor Sony IMX267 (8.9M)
Pixel Size 3.45 µm x 3.45 µm
Shutter type Full frame electronic global shutter function
Full Well charge 10.7ke (max)
Firmware option
(Field programmable)
Standard Design
Monochrome
(factory default)
Standard Design
Bayer
(factory default)
RGB-Output
Design
Max. Internal Frame Rate
Full resolution
30.1 fps
Maximum Sustained Frame Rate
Output (with TurboDrive v1) *
29.6 fps (8-bit)
14.8 fps (12-bit)
N/A
Maximum Sustained Frame Rate
Output (without TurboDrive)
13 fps (8-bit)
6.5 fps (12-bit)
3 fps (RGBA)
5 fps (RGB)
6.5 fps (Yuv422)
13 fps (mono8)
Pixel Data Formats
Mono 8-bit
Mono 12-bit
Bayer 8-Bit
Bayer 12-Bit
RGBA 32-bit
RGB 24-bit
Yuv422 16-bit
Mono 8-bit
Trigger to Exposure Minimum delay
(Synchronous Exposure Alignment)
2 line time (30 µs)
2 line time
(44.84 µs)
Trigger to Exposure Minimum delay
(Reset Exposure Alignment)
0 µs
Trigger to Exposure Start jitter
(best case with Synchronous
Exposure Alignment)
Up to 1 line time
0 to 15 µs
Up to 1 line time
0 to 22.42 µs
Trigger to Exposure Start jitter
(Reset Exposure Alignment)
0 µs
Exposure Time Minimum
(see “exposureTimeActual” in
Sensor Control)
29.26 µs (1 line time + 14.26 us)
(increment steps of 15µs)
36.68 µs
(1 line time + 14.26 us)
(increment steps of
22.42 µs)
Min. Time from End of Exposure to
Start of Next Exposure
10 lines (150 µs)
10 lines
(224.2 µs)
Horizontal Line Time: 15.000 µs 22.42 µs
Readout Time
(Horizontal Line Time) x (lines in frame + 19) μs
(+2H in Reset Exposure Alignment)
Auto-Brightness Yes , with Auto-Exposure and AGC (FPGA Gain or Sensor Gain)
Black offset control Yes (in DN)
Gain Control In-sensor Gain (1.0x to 251x)
In-FPGA Digital Gain (1x to 4x) in 0.007x step
Binning Support
Yes In-FPGA
(summing and
average)
2x2, 4x4
No
Color Correction Support No Yes
Decimation Support No
Defective Pixel Replacement Yes, up to 512 positions
