Dalsa Genie Nano Series User Manual

Nano Series GigE Vision Camera Sony Sensor Models • 53
Specifications: C4060
Supported Features C4060
Resolution 4112 x 2176
Sensor Sony IMX255 (8.9M)
Pixel Size 3.45 µm x 3.45 µm
Shutter type Full frame electronic global shutter function
Firmware option
(Field programmable)
High Sensitivity
Design (Bayer)
(factory default)
Standard Design
(Bayer)
RGB-Output
Design
Full Well charge; dependent on
Firmware Design Loaded
2750e- (max) 10.7ke (max)
Sensitivity to Saturation
4x
1x
Max. Internal Frame Rate
Full resolution
56 fps 46 fps
Maximum Sustained Frame Rate
Output (with TurboDrive v1)*
28 fps (8-bit) N/A
Maximum Sustained Frame Rate
Output (without TurboDrive)
13 fps (8-bit)
3.2fps (RGBA)
4.3 fps (RGB)
6.5 fps (Yuv422)
13 fps (mono8)
Pixel Data Formats Bayer 8-Bit Bayer 8-Bit
RGBA 32-bit
RGB 24-bit
Yuv422 16-bit
Mono 8-bit
Trigger to Exposure Minimum delay
2 line time (15.8µs)
with Synchronous
Exposure Alignment
0 µs with Reset Exposure
Alignment
2 line time (19.5µs)
with Synchronous Exposure Alignment
0 µs with Reset Exposure Alignment
Trigger to Exposure Start
Max 1 line (0 to 7.89µs)
with Synchronous
Exposure Alignment
0 µs with Reset Exposure
Alignment
Max 1 line (0 to 9.72µs)
with Synchronous Exposure Alignment
0 µs with Reset Exposure Alignment
Actual Exposure Time Minimum
(see “exposureTimeActual”
in Sensor Control)
22µs
(1 line time + 14.26 us)
(in 7.89µs steps)
24µs (1 line time + 14.26 us)
(in 9.72µs steps)
Min. Time from End of Exposure to
Start of Next Exposure
16 lines –14.26µs
(112µs)
16 lines – 14.26µs
(141.3µs)
Horizontal Line Time:
Normal operation
(with In-Sensor Binning enable)
7.889 µs
(4.944 µs)
9.722 µs
(5.278 µs)
Readout Time (Horizontal Line Time) x (lines in frame + 28) μs
Auto-Brightness Yes , with Auto-Exposure and AGC (FPGA Gain or Sensor Gain)
Black offset control Yes (in DN)
Gain Control In-sensor Analog Gain (1.0x to 251x)
Binning Support No
Color Correction Support No Yes
Decimation Support No
Defective Pixel Replacement Yes , up to 512 pixel position
Image Correction no
