Dalsa Genie Nano Series User Manual

Nano Series GigE Vision Camera Operational Reference • 183
Maximum Frame Rate Examples (Models M2420 & M2450)
Vertical Lines
Acquired
Internal Trigger
Minimum Exposure
Sony sensor – M2420 Models
Internal Trigger
Minimum Exposure
Sony sensor – M2450 Models
Standard Design Firmware
Internal Trigger
Minimum Exposure
Sony sensor – M2450 Models
High Sensitivity Design
2048 34 fps 76 fps 94 fps
1536 45 fps 101 fps 124 fps
1024 68 fps 150 fps 184 fps
768 90 fps 198 fps 242 fps
512 132 fps 290 fps 355 fps
384 173 fps 379 fps 463 fps
256 251 fps 543 fps 664 fps
128 454 fps 963 fps 1177 fps
64 763 fps 1567 fps 1915 fps
32 1158 fps 2283 fps 2793 fps
16 1560 fps 2958 fps 3623 fps
8 1890 fps 3472 fps 4237 fps
4 2109 fps 3802 fps 4651 fps
Maximum Frame Rate Examples (Models M/C 4040 & 4060)
Increased frame rates with a reduced ROI available only when In-Sensor binning is not active.
Vertical Lines
Acquired
Internal Trigger / Minimum Exposure
Sony sensor – M/C4040 Models
Internal Trigger / Minimum Exposure
Sony sensor – M/C4060 Models
3008 33.6 fps —
2176 46.1 fps 46.1 fps
2048 48.9 fps 48.9 fps
1024 95.4 fps 95.4 fps
512 181.7 fps 181.7 fps
256 331.8 fps 331.8 fps
128 564.6 fps 564.6 fps
64 871.0 fps 871.0 fps
32 1194.7 fps 1194.7 fps
16 1468.4 fps 1468.4 fps
8 1658.3 fps 1658.3 fps
4 1773.0 fps 1773.0 fps
