Dalsa Genie Nano Series User Manual

Nano Series GigE Vision Camera On-Semi Sensor Models • 71
Specifications: M1280, M1280-NIR, C1280
Supported Features M1280, M1280-NIR C1280
Resolution 1280 x 1024
Sensor OnSemi Python1300 P1 (1.3M)
Pixel Size 4.8 µm x 4.8 µm
Shutter type Full frame electronic global shutter function
Full Well charge 10ke (max)
Firmware option
(Field programmable)
Standard Design
Monochrome
(factory default)
Standard Design
Bayer
(factory default)
RGB-Output
Design
Max. Internal Frame Rate
Full Resolution (1280 x 1024)
213 fps (Fast Readout Enable)
174 fps (Normal Readout Enable)
Maximum Sustained Frame Rate
Output (with TurboDrive v1)*
184 fps (8-bit)
92 fps (10-bit)
N/A
Maximum Sustained Frame Rate
Output (without TurboDrive)
88 fps (8-bit)
44 fps (10-bit)
22 fps (RGBA)
33 fps (RGB)
44 fps (Yuv422)
88 fps (8-bit mono)
Pixel Data Formats
Mono 8-bit
Mono 10-bit
Bayer 8-Bit
Bayer 10-Bit
RGBA 32-bit
RGB 24-bit
Yuv422 16-bit
Mono 8-bit
Trigger to Exposure Minimum delay
(Synchronous Exposure Alignment)
4 µs if exposureAlignment = Synchronous With No Overlap
between the new exposure and the previous readout
26.2 µs if exposureAlignment = Synchronous With Overlap
between the new exposure and the previous readout
Trigger to Exposure Minimum delay
(Reset Exposure Alignment)
4 µs
Trigger to Exposure Start jitter (best
case with Synchronous Exposure
Alignment)
Up to 1 line time
Trigger to Exposure Start jitter
(Reset Exposure Alignment) †
0 µs
Exposure Time Minimum
(see “exposureTimeActual” in
Sensor Control)
34 µs
(increment steps of 1µs)
Min. Time from End of Exposure to
Start of Next Exposure (second
frame)
19 µs – Normal Readout
18 µs – Fast Readout
Horizontal Line Time:
5.53 µs – Normal Readout
4.5 µs – Fast Readout
Readout Time
5676 µs – Normal Readout for 1280 x 1024
Add 75µs when overlapping Exposure and Readout
4621 µs – Fast Readout for 1280 x 1024
Add 62µs when overlapping Exposure and Readout
Specifically: ( Horizontal line time at current resolution * number of lines ) + (3
* ( line time of the 1280 model ))
Auto-Brightness Yes , with Auto-Exposure and AGC (FPGA Gain)
Black offset control Yes (in DN)
