Nano Series GigE Vision Camera On-Semi Sensor Models • 69
Specifications: M1240, C1240
Supported Features Nano-M1240 Nano-C1240
Resolution 1280 x 1024
Sensor OnSemi Python1300 P3 (1.3M)
Pixel Size 4.8 µm x 4.8 µm
Shutter type Full frame electronic global shutter function
Full Well charge 10ke (max)
Firmware option
(Field programmable)
Standard Design
Monochrome
(factory default)
Standard Design
Bayer
(factory default)
RGB-Output
Design
Max. Internal Frame Rate
Full Resolution (1280 x 1024)
87 fps (Normal Readout Enable)
Maximum Sustained Frame Rate
Output (with TurboDrive v1)*
87 fps (8-bit)
87 fps (10-bit)
N/A
Maximum Sustained Frame Rate
Output (without TurboDrive)
87 fps (8-bit)
45 fps (10-bit)
22 fps (RGBA)
33 fps (RGB)
45 fps (Yuv422)
87 fps (mono-8)
Pixel Data Formats
Mono 8-bit
Mono 10-bit
Bayer 8-Bit
Bayer 10-Bit
RGBA 32-bit
RGB 24-bit
Yuv422 16-bit
Mono 8-bit
Trigger to Exposure Minimum delay
(Synchronous Exposure Alignment)
6 µs if exposureAlignment = Synchronous With No Overlap
between the new exposure and the previous readout
65 µs if exposureAlignment = Synchronous With Overlap
between the new exposure and the previous readout
Trigger to Exposure Minimum delay
(Reset Exposure Alignment)
6 µs
Trigger to Exposure Start jitter
(best case with Synchronous
Exposure Alignment)
Up to 1 line time
Trigger to Exposure Start jitter
(Reset Exposure Alignment) *
0 µs
Actual Exposure Time Minimum
(see “exposureTimeActual”
feature)†
34 µs
(increment steps of 1µs)
Min. Time from End of Exposure to
Start of Next Exposure
(second frame)
165 µs – Normal Readout
Horizontal Line Time: 11.07 µs – Normal Readout
Readout Time
11351 µs – Normal Readout for 1280 x 1024
Add 150 µs when overlapping Exposure and Readout
Detailed formula : ( Horizontal line time at current resolution * number of lines )
+ (3 * ( line time of the 1280 model ))
Auto-Brightness Yes , with Auto-Exposure and AGC (FPGA Gain)
Black offset control Yes (in DN)
