Dalsa Genie Nano Series User Manual

Nano Series GigE Vision Camera Sony Sensor Models • 31
Specifications: C1950
Supported Features Nano-C1950
Resolution 1932 x 1216
Sensor Sony IMX392 (2.4M)
Pixel Size 3.45 µm x 3.45 µm
Shutter type Full frame electronic global shutter function
Full Well charge; dependent
on Firmware Design Loaded
11ke- (max)
Sensitivity to Saturation 1x
Firmware option:
Field programmable
8-bit Standard
Design
RGB-Output
Design
12-bit Standard
Design (factory default)
Max. Internal Frame Rate
Full resolution
151 fps 151 fps 119 fps
Maximum Sustained Frame
Rate Output
(with TurboDrive v1)
102 fps (8-bit Bayer) N/A
102 fps (8-bit Bayer)
50.1 fps (12-bit Bayer)
Maximum Sustained Frame
Rate Output
(without TurboDrive)
51 fps (8-bit Bayer)
xx fps (RGBA)
xx fps (RGB)
xx fps (Yuv422)
xx fps (8-bit mono)
51 fps (8-bit Bayer)
25.5 fps (12-bit Bayer)
Pixel Data Formats Bayer 8-bit
RGBA 32-bit
RGB 24-bit
Yuv422 16-bit
Mono 8-bit
Bayer 8-bit
Bayer 12-bit
Trigger to Exposure
Minimum delay
2 Line Time with Synchronous Exposure Alignment
0 µs with Reset Exposure Alignment
Trigger to Exposure Start
jitter
0 µs to 1 Line Time with Synchronous Exposure Alignment
0 µs with Reset Exposure Alignment
Actual Exposure Time
Minimum (see
“exposureTimeActual”
feature)
19µs
(increment of 5.2 µs steps)
20 µs
(increment of 6.6 µs steps)
Min. Time from End of
Exposure to Start of Next
Exposure (second frame)
10 lines–13.73µs
(38.97 µs)
10 lines–13.73µs
(52.87 µs)
Horizontal Line Time: 5.278 µs 6.667 µs
Readout Time
(Horizontal Line Time) x (lines in frame + 23) μs
Auto-Brightness Yes , with Auto-Exposure and AGC (FPGA Gain or Sensor Gain)
Black offset control Yes (in DN)
Gain Control
In-sensor Gain (1.0x to 251x)
In-FPGA Digital Gain (1x to 4x) in 0.007x step
Binning Support No
Decimation Support No
Defective Pixel Replacement Yes
Image Correction White Balance (+ Color Correction & Enhancement for RGB Output design)
Image Flip Support Yes, In-Sensor, Vertical and Horizontal
Multi-ROI Support Yes, In-Sensor, up to 16 ROI
