Dalsa Genie Nano Series User Manual

Nano Series GigE Vision Camera Additional Reference Information • 275
Lens Options for Models M/C810
• The following figure shows the lens image circles relative to Genie Nano models using the
Sony IMX433 sensor.
• A typical 2/3” lens will fully illuminate these sensors. A smaller 1/1.7 lens could also be
used.
1" Lens (~16mm)
Image Circle
2/3" Lens (~11mm)
Image Circle
1/1.
7" Lens (~9.2mm)
Image Circle
