Nano Series GigE Vision Camera Sony Sensor Models • 63
Image Correction No
Image Flip Support Yes, In-Sensor, Vertical and Horizontal
Multi-ROI Support Yes, in FPGA, up to 16 ROI (mutually exclusive with binning)
On-Board Image Memory 220MB
Output Dynamic Range (dB) 76.4 dB
SNR (dB) 39.6 dB
* Limited to the Genie Nano Architecture:
~250MB/sec Sustained into the TurboDrive Engine achieved using 1500 Byte Packet Size
Firmware Files for Model 4030 & 4020
The latest firmware files for all Nano models are available on the Teledyne DALSA support web site:
http://www.teledynedalsa.com/imaging/support/downloads/firmware/
The firmware files for these models are listed below. The xx denotes the build number.
M4020 & M4030
• Standard
“Genie_Nano_Sony_IMX267-304_9M-12M_Mono_STD_Firmware_ECA18.xx.cbf”
C4020 & C4030
• Bayer Output
“Genie_Nano_Sony_IMX267-304_9M-12M_Bayer_STD_Firmware_FCA18.xx.cbf”
• RGB Output
“Genie_Nano_Sony_IMX267-304_9M-12M_RGB_Output_Firmware_FCA18.xx.cbf”
