Dalsa Genie Nano Series User Manual

276 • Additional Reference Information Nano Series GigE Vision Camera
Lens Options for Models M/C800
• The following figure shows the lens image circles relative to Genie Nano models using the
OnSemi Python500 sensor.
• A typical 1/3” lens will fully illuminate these sensors.
1/3" Lens (~6mm)
Image Circle
2/
3" Lens
(~11
mm)
Image Circle
1/2" Lens (~
8
mm)
Image Circle
Lens Options for Models M/C700
• The following figure shows the lens image circles relative to Genie Nano models using the
Sony IMX287 sensor.
• A typical ½” lens will fully illuminate this sensor while a 1/3” lens would have some corner
vignetting.
1/3" Lens (~6mm)
Image Circle
2/3" Lens (~11mm)
Image Circle
1/2" Lens (~8mm)
Image Circle
