Nano Series GigE Vision Camera Sony Sensor Models • 51
Specifications: M4060
Supported Features M4060
Resolution 4112 x 2176
Sensor Sony IMX255 (8.9M)
Pixel Size 3.45 µm x 3.45 µm
Shutter type Full frame electronic global shutter function
Firmware option
(Field programmable)
High Sensitivity Design
(8-bit factory default)
Standard Design
8-bit
Standard Design
12-bit
Full Well charge; dependent on
Firmware Design Loaded
2750e- (max) 10.7ke (max) 10.7ke (max)
Sensitivity to Saturation
Max. Internal Frame Rate
Full resolution
56 fps 46 fps 32 fps
Maximum Sustained Frame Rate
Output (with TurboDrive v1)*
28 fps (8-bit)
28 fps (8-bit)
14 fps (12-bit)
Maximum Sustained Frame Rate
Output (without TurboDrive)
13 fps (8-bit)
13.8 fps (8-bit)
6.9 fps (12-bit)
Pixel Data Formats Mono 8-bit Mono 8/12-bit
Trigger to Exposure Minimum delay
(Synchronous Exposure Alignment)
2 line time with Synchronous Exposure Alignment
0 µs with Reset Exposure Alignment
Trigger to Exposure Start jitter
(best case with Synchronous
Exposure Alignment)
0 µs to 1 line with Synchronous Exposure Alignment
0 µs with Reset Exposure Alignment
Actual Exposure Time Minimum
(see “exposureTimeActual”
in Sensor Control)
22 µs
increment in 7.89 µs
steps
24 µs
increment in 9.72 µs
steps
28 µs
increment in 13.9 µs
steps
Min. Time from End of Exposure to
Start of Next Exposure
16 lines –14.26 µs
(112 µs)
16 lines – 14.26 µs
(141.3 µs)
16 lines – 14.26 µs
(208.1 µs)
Horizontal Line Time:
normal operation
with In-Sensor Binning enable
7.889 µs
(4.944 µs)
9.722 µs
(5.278 µs)
13.833 µs
(7.250 µs)
Readout Time (Horizontal Line Time) x (lines in frame + 28) μs
Auto-Brightness Yes , with Auto-Exposure and AGC (FPGA Gain or Sensor Gain)
Black offset control Yes (in DN)
Gain Control In-sensor Analog Gain (1.0x to 251x)
Binning Support
Yes, In-sensor 2x2 (summing)
Yes In-FPGA (summing and average, 2x2, 4x4 )
Decimation Support No
Defective Pixel Replacement Yes , up to 512 pixel position
Image Correction no
Image Flip Support Yes, In-Sensor, Vertical and Horizontal
Multi-ROI Support Yes, In-Sensor, up to 16 ROI (mutually exclusive with in-sensor binning)
On-Board Image Memory 220MB
Output Dynamic Range (dB) 56.7 75.4 dB
SNR (dB) 33.01 39.6 dB
* Limited to the Genie Nano Architecture:
~250MB/sec Sustained into the TurboDrive Engine achieved using 1500 Byte Packet Size
