Dalsa Genie Nano Series User Manual

188 • Operational Reference Nano Series GigE Vision Camera
Maximum Frame Rate Examples (NanoXL M4090)
Using High Speed Firmware (8-bit only)
Vertical Lines
Acquired
Internal Trigger / Minimum Exposure
Python 16k sensor –model M4090
Internal Trigger / Minimum Exposure
Python 16k sensor – model M4090
Fast Readout Mode Enabled
4096 16.5 31.2
3840 17.6 33.4
2560 26.3 49.9
1280 52.5 99.3
640 104.2 196.3
320 205.5 384.0
160 400.0 735.8
80 758.7 1356.8
40 1375.5 2347.4
20 2320.2 3703.7
10 3521.1 5181.3
5 4761.9 6493.5
Note: Fast Readout Mode will have low DN Fixed Pattern column artifacts as described here
OnSemi Sensor Fast Readout Mode.
Using Standard Firmware
Vertical Lines
Acquired
Internal Trigger / Minimum Exposure
Python 16k sensor –model M4090
Internal Trigger / Minimum Exposure
Python 16k sensor – model M4090
Fast Readout Mode Enabled
4096 8.2 15.6
3840 8.8 16.7
2560 13.2 25.0
1280 26.3 49.8
640 53.3 98.2
320 103.6 194.9
160 203.0 378.5
80 390.6 715.3
40 725.7 1288.6
20 1272.2 2155.1
10 2036.6 3236.2
5 2915 4329
