Nano Series GigE Vision Camera Sony Sensor Models • 29
Specifications: M1950
Supported Features Nano-M1950
Resolution 1932 x 1216
Sensor Sony IMX392 (2.4M)
Pixel Size 3.45 µm x 3.45 µm
Shutter type Full frame electronic global shutter function
Full Well charge; dependent on
Firmware Design Loaded
11ke (max)
Sensitivity to Saturation 1x
Firmware option:
Field programmable
8-bit Standard Design
12-bit Standard Design
(Factory Default)
Max. Internal Frame Rate
Full resolution
151 fps 119 fps
Maximum Sustained Frame Rate
Output (with TurboDrive v1)
102 fps (8-bit)
102 fps (8-bit)
50.1 fps (12-bit)
Maximum Sustained Frame Rate
Output (without TurboDrive)
51 fps (8-bit)
51 fps (8-bit)
25.5 fps (12-bit)
Pixel Data Formats Mono 8-bit
Mono 8-bit
Mono 12-bit
Trigger to Exposure Minimum Delay
2 Line Time with Synchronous Exposure Alignment
0 µs with Reset Exposure Alignment
Trigger to Exposure Start Jitter
0 µs to 1 Line Time with Synchronous Exposure Alignment
0 µs with Reset Exposure Alignment
Actual Exposure Time Minimum
(see “exposureTimeActual” feature)
19µs
(increment of 5.2 µs steps)
20 µs
(increment of 6.6 µs steps)
Min. Time from End of Exposure to
Start of Next Exposure (second frame)
10 lines–13.73µs
(38.97 µs)
10 lines–13.73µs
(52.87 µs)
Horizontal Line Time: 5.278 µs 6.667 µs
Readout Time
(Horizontal Line Time) x (lines in frame + 23) μs
Auto-Brightness Yes , with Auto-Exposure and AGC (FPGA Gain or Sensor Gain)
Black offset control Yes (in DN)
Gain Control
In-sensor Gain (1.0x to 251x)
In-FPGA Digital Gain (1x to 4x) in 0.007x step
Binning Support
Yes, In-FPGA
(Summing and Averaging 2x2, 4x4)
Decimation Support No
Defective Pixel Replacement No
Image Correction no
Image Flip Support Yes, In-Sensor, Vertical and Horizontal
Multi-ROI Support Yes, In-Sensor, up to 16 ROI (mutually exclusive with in-sensor binning)
On-Board Image Memory 90MB
Output Dynamic Range (dB) 75.4 dB
SNR (dB) 39.6 dB
