Dalsa Genie Nano Series User Manual

256 • Technical Specifications Nano Series GigE Vision Camera
External Outputs: Using External TTL/LVTTL Drivers
User IO
Ground
User IO
Power
Signal 1
Camera IO
Interface
LVTTL
/TTL
Buffer
R
(
Pull-Down)
R
(Pull-Down)
Signal 2
10 9
8
7
6
5
4 3
2 1
( User IO Power )
( Output 1 )
( Output 2 )
External Outputs: Using External LED Indicators
• Two external LEDs can be connected in the Common Cathode configuration.
User IO
Ground
User IO
Power
Camera IO
Interface
R R
10
9
8
7
6
5
4
3
2
1
( User IO Power )
( Output 1 )
( Output 2 )
Set resistor (R) value to not
exceed output current of
I
F
= 30mA.
!
I
F
I
F
