70 • On-Semi Sensor Models Nano Series GigE Vision Camera
Gain Control
In-sensor Analog Gain (1.0x to 8x) in 11 gain step
(1.0, 1.14, 1.33, 1.6, 2.0, 2.29, 2.67, 3.2, 4.0, 5.33, 8.0)
In-sensor Digital Gain (1x to 32x) in 0.01x step
In-FPGA Digital Gain (1x to 4x) in 0.007x step
Binning Support
Yes In-FPGA
(summing and average,
2x2, 4x4 )
Yes In- Sensor
(averaging 2x2)
No
Color Correction Support No Yes
Decimation Support No
Defective Pixel Replacement Yes, up to 512 positions
Image Correction Yes, Sensor FPN correction feature
Image Flip Support Yes In-Sensor – Vertical Only
Multi-ROI Support Yes in Sensor, up to 16 ROI (mutually exclusive with binning)
On-Board Image Memory 90MB
Output Dynamic Range (dB) 61.8 dB (in 10-Bit Pixel Format)
SNR (dB) 39.7 dB (in 10-Bit Pixel Format)
*TurboDrive internal limitation of 250MB/sec
† Note: The actual internal minimum exposure may be different than what is programmed. Use the feature “exposureTimeActual” from the
Sensor Control category to read back the actual sensor exposure. The exposure start sensor event is delayed 4 µs from the actual start.
Firmware Files for Models 1240
The latest firmware files for all Nano models are available on the Teledyne DALSA support web site:
http://www.teledynedalsa.com/imaging/support/downloads/firmware/
The firmware files for this model are listed below. The xx denotes the build number.
M1240
• Standard
Genie_Nano_OnSemi_Python_P3_1.3M_Mono_STD_Firmware_12CA18.xx.cbf
C1240
• Standard
Genie_Nano_OnSemi_Python_P3_1.3M_Bayer_STD_Firmware_13CA18.xx.cbf
