Nano Series GigE Vision Camera Sony Sensor Models • 25
Specifications: M1920, C1920
Supported Features M1920 C1920
Resolution 1936 x 1216
Sensor Sony IMX249 (2.4M)
Pixel Size 5.86 µm x 5.86 µm
Shutter type Full frame electronic global shutter function
Full Well charge 32.5ke (max)
Firmware option
(Field programmable)
Standard Design
Monochrome
(factory default)
Standard Design
Bayer
(factory default)
RGB-Output
Design
Max. Internal Frame Rate
Full resolution
38.8 fps
Maximum Sustained Frame Rate
Output (with TurboDrive v1)*
38.8 fps (8-bit)
38.8 fps (12-bit)
N/A
Maximum Sustained Frame Rate
Output (without TurboDrive)
38.8 fps (8-bit)
25 fps (12-bit)
13 fps (RGBA)
19.5 fps (RGB)
26 fps (Yuv422)
38.8fps (8-bit mono)
Pixel Data Formats
Mono 8-bit
Mono 12-bit
Bayer 8-Bit
Bayer 12-Bit
RGBA 32-bit
RGB 24-bit
Yuv422 16-bit
Mono 8-bit
Trigger to Exposure Minimum delay
2 line time (41.5 µs) with Synchronous Exposure Alignment
Reset Exposure Alignment not supported
Trigger to Exposure Start jitter
Up to 1 line time (0 to 20.5 µs) with Synchronous Exposure Alignment
Reset Exposure Alignment not supported
Actual Exposure Time Minimum
(see “exposureTimeActual”
in Sensor Control)
34.23 µs (1 line time + 13.73 us)
(increment steps of 20.5 µs)
Min. Time from End of Exposure to
Start of Next Exposure
13 lines (266.5µs)
Horizontal Line Time: 20.525 µs (12-bit)
Readout Time
(Horizontal Line Time) x (lines in frame + 23) μs
Auto-Brightness Yes , with Auto-Exposure and AGC (FPGA Gain or Sensor Gain)
Black offset control Yes (in DN)
Gain Control
In-sensor Gain (1.0x to 251x)
In-FPGA Digital Gain (1x to 4x) in 0.007x steps
Binning Support
Yes In-FPGA
(summing and average)
2x2, 4x4
No
Color Correction Support No Yes
Decimation Support No
Defective Pixel Replacement No
Image Correction No
Image Flip Support Yes, In-Sensor, Vertical and Horizontal
Multi-ROI Support Yes, in FPGA, up to 16 ROI (mutually exclusive with binning)
On-Board Image Memory 90MB
