Dalsa Genie Nano Series User Manual

Nano Series GigE Vision Camera Operational Reference • 189
Maximum Frame Rate Examples (NanoXL M5100)
Using High Speed Firmware (8-bit only)
Vertical Lines
Acquired
Internal Trigger / Minimum Exposure
Python 25k sensor – model M5100
Internal Trigger / Minimum Exposure
Python 25k sensor – model M5100
Fast Readout Mode Enabled
5120 11.8 20.4
3840 15.7 27.2
2560 23.5 40.7
1280 46.9 80.9
640 93.2 160.5
320 184.1 315.2
160 359.1 608.3
80 684.9 1137.7
40 1253.1 2012.1
20 2141.3 3267.9
10 3322.2 4761.9
5 4566.2 6134.9
Note: Fast Readout Mode will have low DN Fixed Pattern column artifacts as described here
OnSemi Sensor Fast Readout Mode.
Using Standard Firmware
Vertical Lines
Acquired
Internal Trigger / Minimum Exposure
Python 25k sensor – model M5100
Internal Trigger / Minimum Exposure
Python 25k sensor – model M5100
Fast Readout Mode Enabled
5120 5.9 fps 10.2 fps
3840 7.8 fps 13.6 fps
2560 11.8 fps 20.4 fps
1280 23.5 fps 40.6 fps
640 46.8 fps 80.7 fps
320 92.7 fps 159.5 fps
160 182.1 fps 311.4 fps
80 351.6 fps 594.5 fps
40 657.9 fps 1089.3 fps
20 1165.5 fps 1865.6 fps
10 1901.1 fps 2907 fps
5 2770 fps 4016 fps
