Nano Series GigE Vision Camera Sony Sensor Models • 37
Specifications: C2050
Supported Features Nano-C2050
Resolution 2064 x 1544
Sensor Sony IMX252 (3.2M)
Pixel Size 3.45 µm x 3.45 µm
Shutter type Full frame electronic global shutter function
Firmware option
(Field programmable)
High Sensitivity
Design (Bayer)
(factory default)
Standard Design
(Bayer)
RGB-Output
Standard Design
Full Well charge; dependent on
Firmware Design Loaded
2750e- (max) 10.7ke (max)
Sensitivity to Saturation 4x 1x
Max. Internal Frame Rate
Full resolution
143 fps 116 fps
Maximum Sustained Frame Rate
Output (with TurboDrive v1) *
82 fps (8-bit) 82 fps (8-bit) N/A
Maximum Sustained Frame Rate
Output (without TurboDrive)
38 fps (8-bit) 38 fps (8-bit)
9.7 fps (RGBA)
14.5 fps (RGB)
19 fps (Yuv422)
38 fps (mono8)
Pixel Data Formats Bayer 8-Bit Bayer 8-Bit
RGBA 32-bit
RGB 24-bit
Yuv422 16-bit
Mono 8-bit
Trigger to Exposure Minimum delay
2 line time (8.8 µs)
with Synchronous Exposure
Alignment
0 µs with Reset Exposure
Alignment
2 line time (10.8 µs)
with Synchronous Exposure Alignment
0 µs with Reset Exposure Alignment
Trigger to Exposure Start
Max 1 line (0 to 4.4µs)
with Synchronous Exposure
Alignment
0 µs with Reset Exposure
Alignment
Max 1 line (0 to 5.4µs)
with Synchronous Exposure Alignment
0 µs with Reset Exposure Alignment
Actual Exposure Time Minimum
(see “exposureTimeActual”
in Sensor Control)
18.1µs (1 line time+13.73
us)
(increment of 4.4µs steps)
19.1µs (1 line time + 13.73 us)
(increment of 5.4µs steps)
Min. Time from End of Exposure to
Start of Next Exposure
10 lines–13.73µs
(30.3 µs)
10 lines–13.73µs
(40.4 µs)
Horizontal Line Time: 4.417 µs 5.417 µs
Readout Time
(Horizontal Line Time) x (lines in frame + 28) μs
Auto-Brightness Yes , with Auto-Exposure and AGC (FPGA Gain or Sensor Gain)
Black offset control Yes (in DN)
Gain Control
In-sensor Gain (1.0x to 251x)
In-FPGA Digital Gain (1x to 4x) in 0.007x steps
Binning Support No
Color Correction Support No Yes
Decimation Support No
