68 • On-Semi Sensor Models Nano Series GigE Vision Camera
Gain Control
In-sensor Analog Gain (1.0x to 8x) in 11 gain steps
(1.0, 1.14, 1.33, 1.6, 2.0, 2.29, 2.67, 3.2, 4.0, 5.33, 8.0)
In-sensor Digital Gain (1x to 32x) in 0.01x steps
In-FPGA Digital Gain (1x to 4x) in 0.007x steps
Binning Support
Yes In-FPGA
(summing and average,
2x2, 4x4 )
Yes In- Sensor
(averaging 2x2)
No
Color Correction Support No Yes
Decimation Support No
Defective Pixel Replacement Yes, up to 512 positions
Image Correction Yes, Sensor FPN correction feature
Image Flip Support Yes, In-Sensor, Vertical Only
Multi-ROI Support Yes, in Sensor, up to 16 ROI (mutually exclusive with binning)
On-Board Image Memory 90MB
Output Dynamic Range (dB) 62.1 dB (in 10-Bit Pixel Format)
SNR (dB) 38.8 dB (in 10-Bit Pixel Format)
*TurboDrive internal limitation of 250MB/sec
† Note: The actual internal minimum exposure may be different than what is programmed. Use the feature
“exposureTimeActual” from the
Sensor Control category to read back the actual sensor exposure. The exposure start
sensor event is delayed 4 µs from the actual start.
Firmware Files for Models 640, 800
The latest firmware files for all Nano models are available on the Teledyne DALSA support web site:
http://www.teledynedalsa.com/imaging/support/downloads/firmware/
The firmware files for these models are listed below. The xx denotes the build number.
M640, M800
• Standard
“Genie_Nano_OnSemi_Python_0.3M-0.5M-1.3M-2M-5M_Mono_STD_Firmware_5CA18.xx.cbf”
• Laser Profiler Firmware
“Genie_Nano_OnSemi_Python_0.3M-0.5M-1.3M-2M-5M_Laser_Profiler_Firmware_5CA18.xx.cbf”
See Application Note: G3-AN0005 on the web site for more details
C640, C800
• Bayer Output
“Genie_Nano_OnSemi_Python_0.3M-0.5M-1.3M-2M-5M_Bayer_STD_Firmware_6CA18.xx.cbf”
• RGB Output
“Genie_Nano_OnSemi_Python_0.3M-0.5M-1.3M-2M-5M_RGB_Output_Firmware_6CA18.xx.cbf”
