Dalsa Genie Nano Series User Manual

22 • Sony Sensor Models Nano Series GigE Vision Camera
Specifications: M1450, C1450
Supported Features M1450 C1450
Resolution 1456 x 1088
Sensor Sony IMX273 (1.6M)
Pixel Size 3.45 µm x 3.45 µm
Shutter type Full frame electronic global shutter function
Full Well charge 11ke (max)
Firmware option
(Field programmable)
Standard Design
Monochrome
(factory default)
Standard Design Bayer
(factory default)
RGB-Output Design
Max. Internal Frame Rate
Full resolution
161 fps at 1456 x 1088 resolution
Maximum Sustained Frame Rate
Output (with TurboDrive v1) *
161 fps at 1456 x 1088 resolution (8-bits)
80 fps at 1456 x 1088 resolution (12-bits)
N/A
Maximum Sustained Frame Rate
Output (without TurboDrive)
75 fps at 1456 x 1088 resolution (8-bits)
36 fps at 1456 x 1088 resolution (12-bits)
19.4 fps (RGBA)
25.9 fps (RGB)
38.9 fps (Yuv422)
77.9 fps (8-bit mono)
Pixel Data Formats
Monochrome 8-bit
Monochrome 12-bit
Bayer 8-bit
Bayer 12-bit
RGBA 32-bit
RGB 24-bit
Yuv422 16-bit
Mono 8-bit
Trigger to Exposure Minimum delay
(Synchronous Exposure Alignment)
2 line time (11 µs)
Trigger to Exposure Minimum delay
(Reset Exposure Alignment)
0 µs
Trigger to Exposure Start jitter (best
case with Synchronous Exposure
Alignment)
Max 1 line time (0 to 5.5 µs)
Trigger to Exposure Start jitter
(Reset Exposure Alignment)
0 µs
Actual Exposure Time Minimum
(see “exposureTimeActual”
in Sensor Control)
19.7 µsec in 5.5 µsec steps (i.e. 1 line time + 14.26 µs)
Min. Time from End of Exposure to
Start of Next Exposure (second
frame)
18 line times – 14.26 µs (84.74 µs)
Horizontal Line Time (H): 5.5 µs (12-bit)
Readout Time
(Horizontal Line Time) x (lines in frame + 22) μs
(-2H in Reset Exposure Alignment)
Auto-Brightness Yes , with Auto-Exposure and AGC (FPGA Gain or Sensor Gain)
Black offset control Yes
Gain Control
In-sensor Analog Gain (1x to 16x)
In-sensor Digital Gain (1 to 16x)
Binning Support
Yes In-FPGA (summing and
average)
2x2, 4x4
NO
Color Correction Support NO
Decimation Support NO
Defective Pixel Replacement NO
