Dalsa Genie Nano Series User Manual

16 • Sony Sensor Models Nano Series GigE Vision Camera
Sony Sensor Models
Genie Nano cameras utilizing Sony sensors (monochrome and color) are described.
Specifications: M700, C700
Supported Features Nano-M700 Nano-C700
Resolution 728 × 544
Sensor Sony IMX287 (0.4M)
Pixel Size 6.9 µm x 6.9 µm
Shutter type Full frame electronic global shutter function
Full Well charge 22ke (max)
Firmware option
(Field programmable)
Standard Design
Monochrome
(factory default)
Standard Design
Bayer
(factory default)
RGB-Output
Design
Max. Internal Frame Rate
Full resolution
310.7 fps
Maximum Sustained Frame Rate
Output (with TurboDrive v1)*
310.7 fps (8-bits and 12-bits) N/A
Maximum Sustained Frame Rate
Output (without TurboDrive)
305 fps (8-bits)
155 fps (12-bits)
76 fps (RGBA)
101 fps (RGB)
155 fps (Yuv422)
305 fps (8-bit mono)
Pixel Data Formats
Mono 8-bit
Mono 12-bit
Bayer 8-Bit
Bayer 12-Bit
RGBA 32-bit
RGB 24-bit
Yuv422 16-bit
Mono 8-bit
Trigger to Exposure Minimum delay
(Synchronous Exposure Alignment)
2 line time (11.0 µs)
Trigger to Exposure Minimum delay
(Reset Exposure Alignment)
0 µs
Trigger to Exposure Start jitter (best
case with Synchronous Exposure
Alignment)
Up to 1 line time
0 to 5.5 µs
Trigger to Exposure Start jitter
(Reset Exposure Alignment)
0 µs
Actual Exposure Time Minimum
(see “exposureTimeActual”
feature)
19.76 µs (1 line time + 14.26 us)
(increment of steps of 5.5 µs)
Min. Time from End of Exposure to
Start of Next Exposure (second
frame)
18 line times – 14.26 μs (84.74 μs)
Horizontal Line Time (H): 5.500 µs (12-bit)
Readout Time
(Horizontal Line Time) x (lines in frame + 22) μs
(-2H in Reset Exposure Alignment)
Auto-Brightness Yes , with Auto-Exposure and AGC (FPGA Gain or Sensor Gain)
Black offset control Yes (in DN)
