Dalsa Genie Nano Series User Manual

274 • Additional Reference Information Nano Series GigE Vision Camera
Lens Options for Models M/C1930
• The following figure shows the lens image circles relative to Genie Nano models using the
OnSemi Python2000 sensor.
• A typical 2/3” lens will fully illuminate these sensors.
1" Lens (~16mm)
Image Circle
2/3
" Lens (
~11mm)
Image Circle
Lens Options for Models M/C1280, M/C1240
• The following figure shows the lens image circles relative to Genie Nano models using the
OnSemi Python1300 sensor.
• A typical ½” lens will fully illuminate these sensors.
1" Lens (~16mm)
Image Circle
2/3" Lens (~11mm)
Image Circle
1/2"
Lens (~8mm)
Image Circle
