Nano Series GigE Vision Camera Sony Sensor Models • 47
Specifications: M2450-Polarized
Resolution 2464 x 2056
Sensor Sony IMX250MZR (5.1M)
Pixel Size 3.45 µm x 3.45 µm
Shutter type Full frame electronic global shutter function
Firmware option
(Field programmable)
12-bit Standard Design
(Monochrome) (factory default)
Full Well charge 11ke (max)
Sensitivity to Saturation 1x
Max. Internal Frame Rate
Full resolution
57 fps
Maximum Sustained Frame Rate
Output (with TurboDrive v1)*
49 fps (8-bit)
25 fps (12-bit)
Maximum Sustained Frame Rate
Output (without TurboDrive)
22 fps (8-bit)
11 fps (12-bit)
Pixel Data Formats Mono 8-bit / Mono 12-bit
Trigger to Exposure Minimum delay
2 line time (12.5 µs)
with Synchronous Exposure Alignment
0 µs with Reset Exposure Alignment
Trigger to Exposure Start
Max 1 line (0 to 6.25µs)
with Synchronous Exposure Alignment
0 µs with Reset Exposure Alignment
Actual Exposure Time Minimum
(see “exposureTimeActual”
in Sensor Control)
19.9µs (1 line time + 13.73 us)
(increment of 6.2µs steps)
Min. Time from End of Exposure to
Start of Next Exposure
10 lines–13.73µs
(48.8 µs)
Horizontal Line Time: 8.333 µs
Readout Time (Horizontal Line Time) x (lines in frame + 28) μs
Auto-Brightness Yes , with Auto-Exposure and AGC (FPGA Gain or Sensor Gain)
Black offset control Yes (in DN)
Gain Control In-sensor Analog Gain (1.0x to 251x)
Binning Support Yes In-FPGA (summing and average) 2x2, 4x4
Decimation Support No
Defective Pixel Replacement No
Image Correction No
Image Flip Support Yes, In-Sensor, Vertical and Horizontal
Multi-ROI Support Yes, In-Sensor, up to 16 ROI (mutually exclusive with in-sensor binning)
On-Board Image Memory 90MB
Output Dynamic Range (dB) 76.4 dB (in 8-Bit Pixel Format)
SNR (dB) 39.4 dB (in 8-Bit Pixel Format)
* Limited to the Genie Nano Architecture:
~250MB/sec Sustained into the TurboDrive Engine achieved using 1500 Byte Packet Size
