Dalsa Genie Nano Series User Manual

Nano Series GigE Vision Camera Sony Sensor Models • 35
Specifications: M2050
Supported Features Nano-M2050
Resolution 2064 x 1544
Sensor Sony IMX252 (3.2M)
Pixel Size 3.45 µm x 3.45 µm
Shutter type Full frame electronic global shutter function
Firmware option
(Field programmable)
High Sensitivity Design
(8-bit factory default)
Standard Design
8-bit
Standard Design
12-bit
Full Well charge; dependent on
Firmware Design Loaded
2750e- (max) 11ke (max) 11ke (max)
Sensitivity to Saturation 4x 1x 1x
Max. Internal Frame Rate
Full resolution
143 fps 116 fps 90.2 fps
Maximum Sustained Frame Rate
Output (with TurboDrive v1) *
82 fps (8-bit)
82 fps (8-bit)
41 fps (12-bit)
Maximum Sustained Frame Rate
Output (without TurboDrive)
38 fps (8-bit)
38 fps (8-bit)
19 fps (12-bit)
Pixel Data Formats Mono 8-bit Mono 8/12-bit
Trigger to Exposure Minimum
delay
2 line time with Synchronous Exposure Alignment
0 µs with Reset Exposure Alignment
Trigger to Exposure
0 µs to 1 line with Synchronous Exposure Alignment
0 µs with Reset Exposure Alignment
Actual Exposure Time Minimum
(see “exposureTimeActual”
in Sensor Control)
18.1 µs
increment in 4.4 µs steps
19.1 µs
increment in 5.4 µs steps
20.7 µs
increment in 7.0 µs steps
Min. Time from End of Exposure
to Start of Next Exposure
10 lines–13.73 µs
(30.3 µs)
10 lines–13.73 µs
(40.4 µs)
10 lines–13.73 µs
(56.3 µs)
Horizontal Line Time: 4.417 µs 5.417 µs 7.000 µs
Readout Time
(Horizontal Line Time) x (lines in frame + 28) μs
Auto-Brightness Yes , with Auto-Exposure and AGC (FPGA Gain or Sensor Gain)
Black offset control Yes (in DN)
Gain Control
In-sensor Gain (1.0x to 251x)
In-FPGA Digital Gain (1x to 4x) in 0.007x steps
Binning Support
Yes In-FPGA (summing and average)
2x2, 4x4
Decimation Support No
Color Correction Support No
Defective Pixel Replacement No
Image Correction No
Image Flip Support Yes, In-Sensor, Vertical and Horizontal
Multi-ROI Support Yes, In-Sensor, up to 16 ROI (mutually exclusive with in-sensor binning)
On-Board Image Memory 90MB
Output Dynamic Range (dB) 56.7 75.4 dB (in 8-Bit Pixel Format)
SNR (dB) 33.01 39.6 dB (in 8-Bit Pixel Format)
