Specifications: M4040 / M4040-Polarized
For an overview of Polarized models see About Polarization
Supported Features
M4040 / M4040-Polarized
Resolution 4112 x 3008
Sensor Sony IMX253 (12M)
Pixel Size 3.45 µm x 3.45 µm
Shutter type Full frame electronic global shutter function
Firmware option
(Field programmable)
High Sensitivity Design
(8-bit factory default)
Standard Design
8-bit
Standard Design
12-bit
Full Well charge; dependent on
Firmware Design Loaded
2750e- (max) 11ke (max) 11ke (max)
Sensitivity to Saturation 4x 1x 1x
Max. Internal Frame Rate
Full resolution
41 fps 33 fps 23.6
Maximum Sustained Frame Rate
Output (with TurboDrive v1) *
21 fps (8-bit)
21 fps (8-bit)
10.7 fps (12-bit)
Maximum Sustained Frame Rate
Output (without TurboDrive)
9.7 fps (8-bit)
9 fps (8-bit)
4.5 fps (12-bit)
Pixel Data Formats Mono 8-bit Mono 8/12-bit
Trigger to Exposure Minimum
delay
2 line time with Synchronous Exposure Alignment
0 µs with Reset Exposure Alignment
Trigger to Exposure Start
0 µs to 1 line with Synchronous Exposure Alignment
0 µs with Reset Exposure Alignment
Actual Exposure Time Minimum
(see “exposureTimeActual”
in Sensor Control)
22 µs
increment of 7.89 µs steps
24 µs
increment of 9.72 µs
steps
28 µs
increment of 13.9 µs
steps
Min. Time from End of Exposure
to Start of Next Exposure
16 lines –14.26 µs
(112 µs)
16 lines – 14.26 µs
(141.3 µs)
16 lines – 14.26 µs
(208.1 µs)
Horizontal Line Time:
normal operation
with In-Sensor Binning enabled
7.889 µs
(4.944 µs)
9.722 µs
(5.278 µs)
13.833 µs
(7.250 µs)
Readout Time (Horizontal Line Time) x (lines in frame + 28) μs
Auto-Brightness Yes , with Auto-Exposure and AGC (FPGA Gain or Sensor Gain)
Black offset control Yes (in DN)
Gain Control In-sensor Analog Gain (1.0x to 251x)
Binning Support Yes In-FPGA (summing and average, 2x2, 4x4 )
Yes, In-sensor 2x2 (summing)
Decimation Support No
Defective Pixel Replacement Yes , up to 512 pixel position
Image Correction no
Image Flip Support Yes, In-Sensor, Vertical and Horizontal
Multi-ROI Support Yes, In-Sensor, up to 16 ROI (mutually exclusive with in-sensor binning)
On-Board Image Memory 220MB
Output Dynamic Range (dB) 56.7 75.4 dB
SNR (dB) 32.01 39.60 dB
* Limited to the Genie Nano Architecture:
~250MB/sec Sustained into the TurboDrive Engine achieved using 1500 Byte Packet Size
