Dalsa Genie Nano Series User Manual

Nano Series GigE Vision Camera Sony Sensor Models • 19
Specifications: M810, C810
Supported Features M810 C810
Resolution 816 x 624
Sensor Sony IMX433 (0.5M)
Pixel Size 9.0 µm x 9.0 µm
Shutter type Full frame electronic global shutter function
Full Well charge 100ke (max)
Firmware option
(Field programmable)
Standard 12-bit Design
Mono (Factory Default)
Standard 12-bit Design
Bayer (Factory Default)
Sensitivity to Saturation 1x
Max. Internal Frame Rate
Full resolution
160 fps
Maximum Sustained Frame Rate
Output (with TurboDrive v1)*
160 fps (8-bit)
160 fps (12-bit)
Maximum Sustained Frame Rate
Output (without TurboDrive)
160 fps (8-bit)
110 fps (12-bit)
Pixel Data Formats
Mono 8-bit
Mono 12-bit
Bayer 8-bit
Bayer 12-bit
Trigger to Exposure Minimum delay
(Synchronous Exposure Alignment)
4 line time with Synchronous Exposure Alignment
0 µs with Reset Exposure Alignment
Trigger to Exposure Start jitter
(best case with Synchronous
Exposure Alignment)
0 µs to 1 line with Synchronous Exposure Alignment
0 µs with Reset Exposure Alignment
Actual Exposure Time Minimum
(see “exposureTimeActual”
in Sensor Control)
14 µs
increment in 9.034 µs steps
Min. Time from End of Exposure to
Start of Next Exposure
13 lines – 4.997 µs
(112 µs)
Horizontal Line Time 9.034 µs
Readout Time
(Horizontal Line Time) x (lines in frame + 41) μs
Readout is interrupted for (8 x Horizontal Line Time) when exposure overlaps
with readout
Auto-Brightness Yes , with Auto-Exposure and AGC (FPGA Gain or Sensor Gain)
Black offset control Yes (in DN)
Gain Control In-sensor Analog Gain (1.0x to 251x)
Binning Support
Yes In-FPGA (summing and average,
2x2, 4x4)
No
Decimation Support No
Defective Pixel Replacement Yes , up to 512 pixel position
Image Correction no
Image Flip Support Yes, In-Sensor, Vertical and Horizontal
Multi-ROI Support Yes, In-FPGA, up to 4 ROI
On-Board Image Memory 90MB
Output Dynamic Range (dB) 73 dB
SNR (dB) 44 dB
* Compression performance varies based on image contents. TurboDrive internal limitation of 250MB/sec.
