240 • Implementing Trigger-to-Image Reliability Nano Series GigE Vision Camera
Implementing Trigger-to-
Image Reliability
Overview
In a complex imaging system a lot can go wrong at all points – from initial acquisition, to camera
processing, to data transmission. Teledyne DALSA provides features, events, and I/O signals that
provide the system designer with the tools to qualify the system in real time.
The Teledyne DALSA website provides general information, FAQ, and White Paper download about
the Trigger-to-Image Reliability (T2IR) framework in hardware and Sapera LT software SDK.
http://www.teledynedalsa.com/imaging/knowledge-center/appnotes/t2ir/
T2IR with Genie Nano
Nano provides a number of features for system monitoring:
• Built-in Self-Test on power-up and reset after firmware change
• Image Buffer Accumulation – Count Status
• Image Buffer Memory Size
• Packet Resend Buffer Memory Size
• Internal Temperature Reporting
• In Camera Event Status Flags
• Invalid External Trigger
• Image Lost
• Packet Resend & Related Status
• Ethernet Pause Frame Requested
Nano Features for T2IR Monitoring
The following table presents some of the Nano camera features a developer can use for T2IR
monitoring. The output line signals would interface to other external devices.
Camera Status Monitoring
Device Built-In Self Test deviceBIST
Device Built-In Self Test Status deviceBISTStatus
Device Temperature Selector DeviceTemperatureSelector
Device Version DeviceVersion
Firmware Version DeviceFirmwareVersion
Last firmware update failed FirmwareUpdateFailure
Manufacturer Part Number deviceManufacturerPartNumber
Manufacturer Info DeviceManufacturerInfo
Events
Event Selector EventSelector
Event Notification EventNotification
