Nano Series GigE Vision Camera Sony Sensor Models • 33
Specifications: M2020, C2020
Supported Features Nano-M2020 Nano-C2020
Resolution 2064 x 1544
Sensor Sony IMX265 (3.2M)
Pixel Size 3.45 µm x 3.45 µm
Shutter type Full frame electronic global shutter function
Full Well charge 10.7ke (max)
Firmware option
(Field programmable)
Standard Design
Monochrome (factory default)
Standard Design
Bayer
(factory default)
RGB-Output
Design
Max. Internal Frame Rate
Full resolution
53.3 fps
Maximum Sustained Frame Rate
Output (with TurboDrive v1) *
53.3 fps (8-bit)
41.0 fps (12-bit)
N/A
Maximum Sustained Frame Rate
Output (without TurboDrive)
38 fps (8-bit)
18 fps (12-bit)
9 fps (RGBA)
13.5 fps (RGB)
18 fps (Yuv422)
38 fps (mono8)
Pixel Data Formats
Mono 8-bit
Mono 12-bit
Bayer 8-Bit
Bayer 12-Bit
RGBA 32-bit
RGB 24-bit
Yuv422 16-bit
Mono 8-bit
Trigger to Exposure Minimum delay
2 line time (23.8 µs) with Synchronous Exposure Alignment
0 µs with Reset Exposure Alignment
Trigger to Exposure Start jitter
Up to 1 line time (0 to 11.9 µs) with Synchronous Exposure Alignment
0 µs with Reset Exposure Alignment
Actual Exposure Time Minimum
(see “exposureTimeActual”
in Sensor Control)
25.65µs (1 line time + 13.73 us)
(increment steps of 11.9µs)
Min. Time from End of Exposure to
Start of Next Exposure (second
frame)
8 lines (81.6 µs)
Horizontal Line Time:
11.917 µs (Synchronous Exposure)
11.750 µs (Reset Exposure)
Readout Time
(Horizontal Line Time) x (lines in frame + 17) μs
(+6H in Reset Exposure Alignment)
Auto-Brightness Yes , with Auto-Exposure and AGC (FPGA Gain or Sensor Gain)
Black offset control Yes (in DN)
Gain Control In-sensor Gain (1.0x to 251x)
In-FPGA Digital Gain (1x to 4x) in 0.007x step
Binning Support
Yes In-FPGA (summing and average)
2x2, 4x4
No
Color Correction Support No Yes
Decimation Support No
Defective Pixel Replacement No
Image Correction No
Image Flip Support Yes, In-Sensor, Vertical and Horizontal
Multi-ROI Support Yes, in FPGA, up to 16 ROI (mutually exclusive with binning)
On-Board Image Memory 90MB
