Nano Series GigE Vision Camera Technical Specifications • 257
• Alternatively one external LED can be connected in the Common Anode configuration.
User IO
Ground
User IO
Power
Camera IO
Interface
R
10
9
8
7
6
5
4
3
2
1
( Output 1 )
( Output 2 )
!
I
F
Set resistor (R) value to not
exceed output current of
I
F
= 30mA.
Only one Output (1 or 2) can
be used in this configuration.
